Mild Steel
Mild Steel
MMB Metal is one of the leading Importer,Exporter,Supplier of Mild Steel Pipes which is used in various industries.Mild Steel Pipes are manufactured according to the International standards namely the American standard [ANSI/ASTM],the British standard [BS EN],and the DIN/ European standard [EN].With years of experience in supplying Mild Steel Pipes we offer high quality lower cost but best service.We are offering Mild Steel Pipes which are used for structural, mechanical and general engineering purpose. These Mild Steel Pipes conform to various standards like ANSI, API, MSS, BS, DIN, JIS & IS standards. We can provide these Mild Steel Pipes in different grades, thickness, length and weight as per the requirements of our clients.
Specification Of Pipe :
|
Size: |
15mm NB to 150mm NB (1/2” to 6”), 7″ (193.7mm OD to 20″ 508mm OD) |
|
Form |
Round, Square, Rectangular, Coil, U Tube, |
|
Length |
As per customer’s requirement (Maximum upto 7 meters) |
|
End |
Plain End, Bevelled End |
|
Type |
Seamless / ERW / Welded |
|
Certification For Mild Steel |
Mill Test Certificate as per EN 10204 / 3.2B |
|
Dimensional Tolerances |
IS: 1239 (Pt I) – 2004, Equivalent to BS – 1387 / 1985 |
|
OD Range |
1.250″ – 6.000″ (30-150mm) |
|
Wall Range |
0.095″ – 1.000″ (.2.5-25mm) |
ASTM A420 WPB Mild Steel Pipe fittings Specification :
|
Standards |
Designation |
|
ASTM |
A 420 |
|
ASME |
B 16.9 |
Mild Steel Flanges :
|
Standards |
Designation |
|
ASTM |
A 105 |
|
ASME |
B 16.5 |
Chemical Compositions ASTM A420 WPB :
|
Element |
Composition, % |
|
Carbon |
0.30 |
|
Manganese |
0.60-1.35 |
|
Phosphorus |
0.035 |
|
Sulfur |
0.040 |
|
Silicon |
0.15-0.30 |
|
Nickel |
0.40 |
|
Chromium |
0.30 |
|
Molybdenum |
0.12 |
|
Vanadium |
0.08 |
